D301087 0308 - BL20 CANopen 4-263
I/O-Module Objects
4
Meaning of the 4-bit process output data on an SWIRE-DIL device:
The following table shows the meaning of the data bits:
Bit 7 Bit 6 Bit 5 Bit 4
free
free free SOx
Table 178:
Meaning of the
data bits
Designa-
tion
Status Comment
SOx Relay x
relay x
SOx is transferred as the switch status of
the contactor coil from the SWIRE bus
master to the appropriate SWIRE bus
slave.
0 OFF OFF Contactor not switched on
1 ON ON Contactor is switched on
