D301087 0308 - BL20 CANopen 3-7
Technical Data
3
Resistance to vibration according to IEC 61131-2
10 to 57 Hz, Constant
amplitude 0.075 mm /
0.003 inch, 1g
Yes
57 to 150 Hz, Constant
acceleration 1 g
Yes
Mode of vibration Frequency sweeps with a
change in speed of
1 Octave/min
Period of oscillation 20 frequency sweeps per axis
of coordinate
Shock resistant according to
IEC 68-2-27
18 shocks, sinusoidal half-
wave 15 g peak value/11 ms,
in each case in +/- direction
per space coordinate
Resistance to repetitive shock
according to IEC 68-2-29
1 000 shocks, half-sinus 25 g
peak value/6 ms, in each case
in +/- direction per space
coordinate
Topple and fall according to IEC 68-2-31 and free fall according
to IEC 68-2-32
Weight < 10 kg
Height of fall 1.0 m / 39.37 inch
Weight 10 to 40 kg
Height of fall 0.5 m / 19.69 inch
Test runs 7
Device with packaging, electrically tested printed-circuit board
