Tuttnauer 5050 - Utilities; Load on Counter

Page 14
Caution!
Waste water should be brought into the public net in accordance
with the local rules or requirements i.e ONLY NON-HAZARDOUS
LIQUIDS SHALL BE DISPOSED IN PUBLIC SEWAGE!
3.6 Utilities
Property
Value
Compressed Air (C, cooling models
only)
1/2" 3-4 Bar
Tap water (C, cooling models only)
1/2", 2-6 Bar
Drain (C, cooling models only)
Withstanding temp. of
80°C
Model
Power
consumption
Supply
Voltage
Line
current
Protection against
electrical shock
5075
6 x 1100W
3 Ph,
400V/50Hz
10A
IEC 61010-1
5050
4 x 1100W
3 Ph,
400V/50Hz
10A
IEC 61010-1
Attention:
The electrical net must be protected with a current leakage
safety relay.
The electrical network must comply with local rules or
regulations.
3.7 Load on counter
The counter (or shelve, etc.) on which the autoclave shall be placed
must be able to withstand, at least, the following weight:
Model
5050
5075
Weight
285 kg
310 kg
