Tuttnauer 5050 - Description and Functions of the Front Panel Keyboard

Page 24
4.2 Description and Functions of the Front Panel
Keyboard
The front panel is composed of 3 sections:
1. Display screen.
2. Keypad.
3. Printer
Display screen
The display is an LCD panel used to display the current status of the
autoclave while using Operational Messages and Error Messages.
Chamber temperature No. 1
• System status
• Name of stage
• Error and operational
messages
• Program description:
• Program icon and name
• Sterilization temperature
• Sterilization time
Chamber pressure
Chamber temperature No. 2
