Page 25
Keypad
The keypad consists of three keys as described below:
UP key
This key has the following functions:
• In the menu directories:
o This key enables the operator to browse through the
cycles.
• In the directories available:
o When the cursor is blinking on a number, the UP ▲ key
increases its value.
o When the cursor is blinking on a menu selection, the UP
▲ key allows browsing backward through the menu.
o When adjusting a parameter and the cursor is blinking
on “SET” or “EXIT” the UP ▲ key activates that
procedure.”
DOWN key
This key has the following functions:
• In the menu directories:
o This key enables the operator to browse through the
cycles.
• In the directories available:
o When the cursor is blinking on a number, the DOWN ▼
key decreases its value.
o When the cursor is blinking on menu selection, the
DOWN ▼ key allows browsing forward through the
menu.
o When adjusting a parameter and the cursor is blinking
on “SET” or “EXIT” the
DOWN ▼ key activates that procedure.
START/STOP key
This key has the following functions:
• In the main screen:
o Starts the process when the required program was
chosen.
o Stops the current process.
o Cancels the ERROR message displayed on the screen
and opens the electric door lock.
• In the menu directories:
o When the cursor is blinking on a number, the
