SARA-R4/N4 series-AT Commands Manual

UBX-17003787 - R09



BAppendix: AT Commands List

Page 278 of 307

GPIO interface

AT command

+UGPIOC

+UGPIOR

+UGPIOW

R404M-00B • • •

R410M-01B • • •

R410M-02B • • •

R412M-02B • • •

R410M-52B • • •

SARA

N410-02B • • •
