SARA-R4/N4 series-AT Commands Manual

UBX-17003787 - R09



14System features

Page 155 of 307

- SARA-R4 / SARA-N4 - 64 pins

o When a non-testable pin is selected, the command does not return an error result code but the value is

not considered and not applied.

o The status of the n-th pin will be represented by the corresponding n-th bit; see the <op_code>

description for the notation of each mode setting

o Convert each group of four binary digits into its hexadecimal representation

SARA-R4 / SARA-N4

See the End User Test Application Note [133] for the list of pins available for testing.

• An example of the AT commands sequence to test the digital pins is reported in Table 14.

Command Response Description

Configure the formatting of the error result code by

means of +CMEE AT command

AT+COPS=2 OK Deregister the module from the network

AT+UTEST=1 OK The module enters the test mode

AT+UTEST=10,2,"000007F400

C000D83F00"

OK The command puts the module in Interface initialised

state; the command saves the pins status to restore it

at the end of the test.

Pins enabled for testing: DSR, RI, DCD, DTR, RTS, CTS,

GPIO1, GPIO2, GPIO3, GPIO4, I2S1_RXD/GPIO6, I2S1_TXD/

GPIO7, GPIO5, I2S1_CLK/GPIO8, I2S1_WA/GPIO9, SPI_

SCLK/GPIO10, SPI_MOSI/GPIO11, SPI_MISO/GPIO12, SPI_

SRDY/GPIO13, SPI_MRDY/GPIO14

AT+UTEST=10,3,"0000049400

4000C01800"

OK Pins configuration:

o DTR, RTS, GPIO3, GPIO4, I2S1_RXD/GPIO6, GPIO5,

I2S1_CLK/GPIO8, SPI_MOSI/GPIO11, SPI_MRDY/

GPIO14 as input

o DSR, RI, DCD, CTS, GPIO1, GPIO2, I2S1_TXD/

GPIO7, I2S1_WA/GPIO9, SPI_SCLK/GPIO10, SPI_

MISO/GPIO12, SPI_SRDY/GPIO13 as output

AT+UTEST=10,4,"0000036000

8000182700"

OK Digital logic value of the output pins:

o DSR, RI, DCD, CTS, GPIO1, GPIO2, I2S1_TXD/

GPIO7, I2S1_WA/GPIO9, SPI_SCLK/GPIO10, SPI_

MISO/GPIO12, SPI_SRDY/GPIO13 set to "high".

AT+UTEST=10,5 OK Configurations made by AT+UTEST=10,2; AT+UTEST=

10,3 and AT+UTEST=10,4 are executed.

AT+UTEST=10,6 000007F400C000D83F00

Logic digital value measured at modules pins:

o DSR, RI, DCD, DTR, RTS, CTS, GPIO1, GPIO2, GPIO3,

GPIO4, I2S1_RXD/GPIO6, I2S1_TXD/GPIO7, GPIO5,

I2S1_CLK/GPIO8, I2S1_WA/GPIO9, SPI_SCLK/GPIO10

, SPI_MOSI/GPIO11, SPI_MISO/GPIO12, SPI_SRDY/

GPIO13, SPI_MRDY/GPIO14: "high" level detected

AT+UTEST=0 OK Module exits from the test mode and normal pins

configurations is restored.

Table 14: Digital pins test command examples

The digital pins can be configured as many times as needed by the testing process; AT+UTEST=10,2

command is not needed any more as the DUT is already in Interface initialised state.

14.6Internal temperature monitor +UTEMP

+UTEMP

SARA-R410M-52BModules

SARA-N4

Syntax PIN required Settings saved Can be aborted Response time Error referenceAttributes

partial No No No - +CME Error

14.6.1Description

Returns the values of internal temperature sensors of the specified unit.
