SARA-R4/N4 series-AT Commands Manual
UBX-17003787 - R09

9Short Messages Service
Page 86 of 307
Parameter Type Description
• Relative format: validity period starting from when the SMS is received by the
SMSC, in range 0-255 (default value 167); for more details see 3GPP TS 23.040 [8]
<vp> Validity period value
0 to 143 (TP-VP + 1) x 5 minutes (i.e. 5 minutes
intervals up to 12 hours)
144 to 167 12 hours + ((TP-VP -143) x 30 minutes)
168 to 196 (TP-VP - 166) x 1 day
197 to 255 (TP-VP - 192) x 1 week
• Absolute format: absolute time of the validity period termination in string format
("yy/MM/dd,hh:mm:ss+zz") (refer to 3GPP TS 23.040 [8]); the time zone is
expressed in steps of 15 minutes. The range goes from -48 to +56
<mr> Number Message reference
<ra> String Recipient address field
<tora> Number Type of address of <ra> - octet
<scts> String Service center time stamp in time-string format, refer to <dt>
<dt> String Discharge time in format "yy/MM/dd,hh:mm:ss+zz"; the time zone is expressed in
steps of 15 minutes. The range goes from -48 to +56
<st> Number Status of an SMS STATUS-REPORT
<ct> Number TP-Command-Type (default 0)
<mn> Number 3GPP TS 23.040 [8] TP-Message-Number in integer format
<mid> Number CBM message identifier
<cdata> String TP-Command-Data in text mode responses
<sn> Number CBM serial number
<page> Number 3GPP TS 23.041 [9] CBM page parameter bits 4-7 in integer format
<pages> Number 3GPP TS 23.041 [9] CBM page parameter bits 0-3 in integer format
9.18List concatenated message +UCMGL
+UCMGL
SARA-R410M-02B SARA-R410M-52B SARA-R412MModules
SARA-N4
Syntax PIN required Settings saved Can be aborted Response time Error referenceAttributes
full Yes No No Up to 3 min (<1
s for prompt ">"
when present)
+CMS Error
9.18.1Description
Returns SMS messages with status value <stat> from message storage <mem1> to the DTE and shows
additional information when the message is a segment of a concatenated one:
• SMS-DELIVER: the parameters <tooa>, <length> shall be displayed only if +CSDH=1 is set.
• SMS-SUBMIT: the parameters <toda>, <length> shall be displayed only if +CSDH=1 is set.
If status of the received message is "received unread", status in the storage changes to "received read".
The command is supported only for text mode (+CMGF=1).
9.18.2Syntax
Type Syntax Response Example
Set AT+UCMGL[=<stat>] SMS-DELIVERs:
+UCMGL: <index>,<stat>,<oa>,
[<alpha>],[<scts>][,<tooa>,
<length>][,<seq>,<max>,<iei>,
<ref>]
<data>
[+UCMGL: <index>,<stat>,<oa>,
[<alpha>],[<scts>][,<tooa>,
AT+UCMGL
+UCMGL: 304,"REC READ","+39340
1234999",,"08/08/06,10:01:38+08",
145,152,1,2,8,32767
