SARA-R4/N4 series-AT Commands Manual
UBX-17003787 - R09

7Network service
Page 55 of 307
7.9.2î™–î™–î™–î™–Syntax
Type Syntax Response Example
Set
AT+VZWAPNE=<wapn>,<apncl>,
<apnni>,<apntype>,<apnb>,
<apned>,<apntime>
OK AT+VZWAPNE=1,1,"VZWIMS",
"IPv6","LTE","Enabled",0
OK
Read
AT+VZWAPNE?
[+VZWAPNE: <apncl>,<apnni>,
<apntype>,<apnb>,<apned>,
<apntime> [..]]
OK
+VZWAPNE: 1,"VZWIMS","IPv4v6",
"LTE","Enabled",0
+VZWAPNE: 2,"VZWADMIN",
"IPv4v6","LTE","Enabled",0
OK
Test AT+VZWAPNE=? +VZWAPNE: (list of supported
<wapn>s),(list of supported
<apncl>s),,(range of supported
<apntype>s),range of supported
<apnb>s),(list of supported
<apned>s),(list of supported
<apntime>s)
OK
+VZWAPNE: (0-4),(1-4),,("IPv6",
"IPv4v6"),("LTE"),("Enabled",
"Disabled"),(0-1023)
OK
7.9.3î™–î™–î™–î™–Defined values
Parameter Type Description
<wapn> Number APN list entry
<apncl> Number APN class
<apnni> String Network identifier:
• "VZWIMS": Verizon wireless IMS PDN
• "VZWADMIN": Verizon wireless administrative PDN
• "VZWINTERNET": Verizon Internet PDN
• "VZWAPP": Verizon wireless application PDN
The previous strings are predefined but others could be accepted.
<apntype> String
• "IPv6": IPv6 type
• "IPv4v6" (factory-programmed value): IPv4 and IPv6 type
<apnb> String APN bearer:
• "LTE" (factory-programmed value): LTE bearer used
<apned> String Enable/disable the APN:
• "Enabled" (factory-programmed value): APN enabled
• "Disabled": APN disabled
<apntime> Number APN inactivity timer value in minutes. The range goes from 0 to 5. Value '0' (factory-
programmed value) sets the timer to infinity.
7.9.4î™–î™–î™–î™–Notes
APN class APN NI IP type APN bearer Enable flag WAIT_TIME Description
1 VZWIMS Ipv4v6 LTE Enabled 0 IMS
2 VZWADMIN Ipv4v6 LTE Enabled 0 Administrative
3 VZWINTERNET Ipv4v6 LTE Enabled 0 Internet
4 VZWAPP Ipv4v6 LTE Enabled 0 Application
Table 5: Factory-programmed APN table setting
