116 Individual phone configuration
Network information
This overview in the user area of the menu provides you with information about
the IP address of the phone and the HTML address of the web interface. It also
provides real-time data about the network activity of the phone.
Settings Open the menu
Page 19.
Select and confirm the option shown.
if nec.
j Enter and confirm the user password.
Select and confirm the option shown. You can browse the following overview:
IP address: Displays the IP address or name that was assigned to the phone in
the network.
WBM URL: HTTP address of the web interface. This address is specified in the
address line of the Internet browser and is used to call the web interface of the
phone in the browser.
LAN/PC byte input: The network or PC interface data packets received are
illustrated dynamically as columns.
LAN/PC byte output: The network or PC interface data packets sent are
illustrated dynamically as columns.
LAN/PC autonegotiated: [Yes|No]: Displays whether the network or PC
interface data transfer rate is set to automatic (Yes) or manual (No).
LAN/PC port speed: [10|100|1000] Mbit/s: Data transfer rate of the network or
PC interface. If an interface is not in use, Link down is displayed.
