UniPOS Fire Extinguishing Control Panel FS5200Е
Instruction Manual Page 54
Revision 7/06.12 of 63
13.4.2.6.3.4. Number of the addressable
device FD7203.
Admissible values of the parametres are:
01÷125 (address of the device in the relevant
loop).
Аctive buttons :
 to change – buttons and
;
 to save the change – button
(„Мenu”);
 to exit - button („Exit”).
1 2 3
13.4.2.6.3.5. Number of the input of the
addressable device FD7203.
Admissible values of the parameter are 01,
02 and 03 (IN1, IN2 and IN3 of FD7203).
Аctive buttons :
 to change – buttons and ;
 to save the change – button
(„Мenu”);
 to exit - button („Exit”).
1 2 3
The procedure for inserting parametres for inputs ''Manual/AutomaticMode'',''Disable
Extinguishing'' and ''Hold Extinguishing“ is performed analogically according to the described in
articles 13.4.2.6.3.1.÷13.4.2.6.3.5. and operations.
