Unitec Wash Select II User Manual

W A S H S E L E C T I I
Document Number: WS21002 186
Document Title: WSII Operations Manual
6. Drop the six sample tokens of the second type, and note that the LED blinks
multiple times after the last token
7. Replace the rotary switch to 0
8. Replace the cover
Refer to the following table for your token information.
Table 33. Wash Select II Token Values
Name
Default Setting
Maximum Allowed
Token Value
$1.00
$99.00
Maximum Tokens per
Transaction
80
80
Figure 33. Outside/Inside of IDX Coin Acceptor
NOTE: The IDX coin-acceptor can be programmed to divert either the $1 coin or a quarter.
The diverted coin needs to be programmed to be on pin 6 of the IDX always.
The table below lists the programming structure.
