W A S H S E L E C T I I
Document Number: WS21002 31
Document Title: WSII Operations Manual
 Wash Fault – on when there is a fault with the car wash (wash is down), this is an
optional input
 Auxiliary 1 – spare output on Display I/O board for EXT Fleet card
 Auxiliary 2 – spare output on Display I/O board for EXT Fleet Card
2.4.4 Testing Coin and Bill Pulse Relays
Using this feature, you can test the coin dispenser and the bill validator without affecting the
account report. This test also allows you to enter cash without having the cash acceptance
disabled as it would automatically do in normal operational mode once you have paid for the
most expensive wash.
To enter the “Test Bills/Coins” menu, follow the steps below.
1. Using the toggle switch at the top of the CPU board, place the Wash Select II in
setup mode by moving the switch toward the back of the Wash Select II case.
(The CPU board is located on the inside right wall of the Wash Select II case.)
2. Using the (3) key to scroll forward and the (1) key to scroll back, scroll through the
main menu until the "Diagnostics" option is displayed. Press the (*) key to enter.
3. Use the (3) key to scroll until the "Test Bills/Coins" option is displayed. Press the
(*) key to enter.
4. Begin to insert coin, bills, or tokens.
The main display screen will show the total cash and tokens. The wash display screens will
show the pulse count for each input. You may clear the totals at any time by pressing the (*)
key.
Inputs for the USA version (Country Code = USA) are defined as follows:
