Operation and Specifications 2.9 - Specifications
TM12 Work Platform - European
2.9 S
PECIFICATIONS
Specifications are subject to change without notice. Hot weather or heavy use may affect performance.
The TM12 meets or exceeds all applicable CE and GS requirements.
ITEM SPECIFICATION
Platform Size 0,74 m x 1,04 m (29 in. x 41 in.) Inside Toeboards
Maximum Platform Capacity 227 kg (500 lbs.)
Maximum Number of Occupants Two people
Height
Working Height 5,49 m (18 ft.)
Maximum Platform Height 3,66 m (12 ft.)
Minimum Platform Height 0,48 m (19 in.)
Dimensions
Weight 776 kg (1710 lbs.)
Overall Width 0,76 m (30 in.)
Overall Height 1,64 m (64.75 in.)
Overall Length 1,36 m (53.5 in.)
Driveable Height 3,66 m (12 ft.)
Drive Speed
Platform Lowered 3,65 km/h (2.27 mph)
Platform Raised 0,99 km/h (.62 mph)
Energy Source 24V battery pack
Four 220 ampere hour, 6 Volt batteries, min. wt. 28,12 kg (62 lbs.) each
4HPDCelectricmotor
System Voltage 24 VDC
Battery Charger 20 AMP, 110/220 VAC
Hydraulic Tank Capacity 7,2 L (1.9 gal)
Maximum Hydraulic System
Pressure
207 bar (3000 psi)
Hydraulic Fluid
Above 0° C [32° F]
Below 0° C [32° F]
Below -17° C [0° F]
ISO #46
ISO #32
ISO #15
Lift System One Single Stage Lift Cylinder
Drive Control Proportional
Control System Proportional Control Handle with Interlock, Selector Switch,
Red Mushroom Emergency Stop Switch
Drive System Dual Front Wheel Hydraulic Motors
Tires 30,5 cm (12 in.) diameter solid rubber, Non-marking
Parking Brakes Dual, Spring Applied, Hydraulic Release
Turning Radius 37 cm (14.5 in.) Inside
Maximum Gradeability 14º (25%)
Wheel Base 97,8 cm (38.5 in.)
Guardrails 1,14 m (45 in.)
Toeboard 152 mm (6 in.)
