Page
3-
5
Maintenance
3.6
-
Parts
Locat
ion
TM12
Work
Plat
form
-
Europe
an
3.6
P
ARTS
L
OCATI
ON
Figur
e
3-5:
Parts
Loc
at
ion
Electrical
Box
Assembly
107008-001
Controller
Assembly
107010-000
Hydraulic
Reservoir
Assembly
107007-000
Batteries
6
Volt
015796-000
Tilt
Sensor
Assembly
029945-021
Battery
Charger
063948-003
Control
Valve
Assembly
101120-021
Power
Unit
101230-000
Control
Cable
Assembly
107009-000
Drive
Relief
Valve
Assembly
107006-000
Motor
Control
065708-001
Dip
Switch
Settings
Dip
Switch
Settings
Fuse
010148-000
Circuit
Board
065709-001
Relay
010122-000
Cylinder
Valve
Assembly
107005-000
Hydraulic
Oil
Filter
005154-001
30
32
