Upright TM12 Service & Parts Manual

Page 6-6
Illustrated Parts Breakdown - Basic Assembly
TM12 Work Platform - European
Basic Assembly
107001-000
ITEM PART NO. DESCRIPTION QTY
1 065562-001 INNER MOUNT 2
2 065561-001 ANCHOR INNER 2
3 065552-000 ADAPTER 1
4 065542-001 OUTER ANCHOR 1
5 065540-000 OUTER MOUNT 2
6 065539-001 OUTER AXLE 1
7 065538-001 INNER AXLE 1
8 065491-001 SECOND INNER MAST WEDMENT 4M 1
9 065488-001 LOWER INNER MAST WELDMENT 1
10 065485-003 BASE MAST WELDMENT 1
11 065450-001 CYL. BAR & PAD WELDMENT 1
12 107002-000 CHASSIS ASSY MAST LIFT 1
- 065398-010 SEAL KIT -
13 065398-003 CYL LIFT TM12 1
14 065389-000 FRONT PAD 12
15 065388-000 REAR PAD 12
16 065387-001 PULLEY OUTER 1
17 065386-001 PULLEY INNER 1
18 065383-001 PIN 3
19 065382-001 ANCHOR PIN 2
22 062642-019 BEARING 7/8 ID X 3/4 LG 2
23 062167-103 CHAIN LEAF 4
24 065580-001 PLATFORM WELDMENT REF
25 065366-020 SWITCH, PROXIMITY ASSY 1
26 013336-011 GREASE ZERK 4
28 011828-010 SCREW, 1/4-20 X 1 1/4 FH 2
29 011821-006 SCREW, 1/4-20 X 3/4 BH 6
30 012553-012 SCREW 1/4-20UNC SOC HD x 1 1/2 2
31 011979-006 O-RING 1
32 011253-004 SCREW 5/16-18UNC HHC X 1/2 6
33 013315-009 RING RETAINING 1
34 011941-009 FITTING STR 8MB-6MJ 2
35 011248-006 LOCKNUT 3/8-16UNC HEX 2
36 011248-008 LOCKNUT 1/2-13UNC HEX 1
37 011256-016 SCREW 1/2-13UNC HHC X 2 1
38 013923-004 SCREW #10-ABHWH X 1/2 44
39 012553-010 SCREW 1/4-20UNC SOC HD x 1 1/4 2
41 012553-006 SCREW 1/4-20UNC SOC HD X 3/4 12
42 026553-001 POP-RIVET 3/16 X 1/8 GRIP 4
43 011264-210 SCREW HHC GR8 3/8-24 UNF X 1 1/4 9
44 011735-005 ROLL PIN 1/8 x 5/8 6
45 011751-006 COTTER PIN 1/16 X 3/4 4
47 011239-006 WASHER, FLAT ASTM A325 3/8 18
48 011261-106 NUT, HEX GR8 3/8-24 UNF 9
49 013949-003 WASHER #10 EXT. STAR 44
50 063096-010 FUSE VELOCITY 1
51 011240-006 WASHER 3/8 STD FLAT 4
52 011254-032 SCREW, HHC. 3/8-16 X 4 2
ITEM PART NO. DESCRIPTION QTY

Upright TM12 Specifications

General

Brand	Upright
Model	TM12
Category	Lifting Systems
Language	English
