Page 6-13

Illustrated Parts Breakdown -HoseKit

TM12 Work Platform - European

Hose Kit

107011-000

ITEM PART NO. DESCRIPTION QTY

1 065419-042 HOSE ASSY 1/4 X 42 (6FJX-6FJX) 1

2 107092-028 HOSE ASSY 1/4 X 28 (6FJX-6FJX X 90) 2

3 107188-000 CYLINDER TUBE ASSY (SS) 3/8 DIA. REF

4 065419-013 HOSE ASSY 1/4 X 13 (6FJX-6FJX) 1

5 068965-017 HOSE ASSY 3/8 X 17 (6FJX-6FJX X 90) 1

6 068965-038 HOSE ASSY 3/8 X 38 (6FJX-6FJX X 90) 1

7 065419-011 HOSE ASSY 1/4 X 11 (6FJX-6FJX) 1

8 107091-047 HOSE ASSY 3/16 X 47 (4FJX-4FJX X 90) 1

9 107092-020 HOSE ASSY 1/4 X 20 (6FJX-6FJX X 90) 2

10 107090-035 HOSE ASSY 1/4 X 35 (4FJX-4FJX X 90) 1

11 107090-029 HOSE ASSY 1/4 X 29 (4FJX-4FJX X 90) 1

12 107091-024 HOSE ASSY 3/16 X 24 (4FJX-4FJX X 90) 1

13 061351-053 HOSE ASSY 1/8 X 27 (4FJX-4FJX) 1

14 061789-026 HOSE ASSY 3/4 X 26 (12FJX-12MP) 1

15 068965-018 HOSE ASSY 3/8 x 18 (6FJX-6FJX X 90) 1

16 060861-054 HOSE ASSY 3/8 X 40 1/2 (6FJX - 6FJX) 1

17 020032-003 FITTING, TEE #6 REF

18 020733-001 FITTING, TEE #4 REF

19 107091-024 HOSE ASSY 3/16 X 24 (4FJX-4FJX X 90) 4

21 065369-099 HOSE GUARD NYLON X 18” REF

ITEM PART NO. DESCRIPTION QTY
