Page 6-2
Illustrated Parts Breakdown -FinalAssembly
TM12 Work Platform - European
Final Assembly
107000-001
ITEM PART NO. DESCRIPTION QTY
1 065543-000 COVER 4M 1
2 065536-000 TOP COVER 1
3 065580-001 PLATFORM WELDMENT 1
5 107012-001 DECAL KIT INSTL (NOT SHOWN) 1
6 107011-000 HOSE KIT (NOT SHOWN) 1
7 107010-000 CONTROLLER ASSY 1
8 107008-001 ELEC. BOX ASSY 1
9 029601-020 CONNECTOR RING 10-12 GA 1/4 2
10 107001-000 BASIC ASSY 1
11 029945-021 LEVEL SENSOR ASSY 1
12 010080-006 T-CLIP 4
13 063948-003 BATTERY CHARGER 1
14 010154-000 C0VER BATTERY TERMINAL 8
15 015796-000 BATTERY 6V 4
- 015796-000 BATTERY 6V (DRY) -
16 107009-000 CONTROL CABLE ASSY 1
17 013919-018 CLAMP 2
18 107192-000 VALVE BLOCK CABLE ASSY 1
19 107193-000 LOWER CONTROL CABLE ASSY 1
20 107194-000 CHASSIS CABLE ASSY 1
21 011240-005 WASHER 5/16 STD FLAT 4
22 011248-005 LOCKNUT 5/16-18UNC HEX 10
23 011253-006 SCREW 5/16-18UNC HHC X 3/4 2
24 026616-008 NIPPLE 1 CHASE 1
25 029939-004 LOCKNUT 1 NPT 1
26 013923-004 SCREW #10 SLFTP X 1/2 4
27 011252-006 SCREW 1/4-20UNC HHC X 3/4 9
28 011829-006 BOLT 1/4-20UNC CARRIAGE X 3/4 8
29 011248-004 LOCKNUT 1/4-20UNC HEX 7
30 011240-004 WASHER 1/4 DIA STD FLAT 6
31 064195-050 BATTERY CABLE ASSY 5/16-5/16 X 50 1
32 062125-016 BATTERY CABLE ASSY 5/16-3/8 X 16 2
33 064195-008 BATTERY CABLE ASSY 5/16-5/16 X 8 3
34 064195-014 BATTERY CABLE ASSY 5/16-5/16 X 14 1
35 014252-004 NUTSERT 1/4-20 UNC 4
36 064195-018 BATTERY CABLE ASSY 5/16-5/16 X 18 1
37 064195-043 BATTERY CABLE ASSY 5/16-5/16 X 43 1
38 107188-000 CYL TUBE ASSY (NOT SHOWN-SEE HOSE KIT) 1
39 065369-001 HOSE GUARD X 18 (NOT SHOWN-SEE HOSE KIT) 2
40 065589-000 TOEBOARD 1
41 020495-010 NUT HEX JAM 5/16-18 8
42 030768-001 LABEL CE (NOT SHOWN) 1
43 014924-001 U-BOLT 5/16-18NT 4
44 066594-000 MIDRAIL WELDMENT 2
45 018290-010 TUBE 2 OD X .219 WALL X 10 3/4 LG 1
46 107081-000 WELDMENT, BALLAST 2
47 107015-000 HYD SCHM REF
48 107016-001 ELEC SCHM REF
50 110010-001 SPECIFICATION SHEET REF
