Page 3-1TM12 Work Platform - European
Section 3
M
AINTENANCE
3.1 I
NTRODUCTION
This section contains instructions for the maintenance of the Work Platform. Procedures for the
operation inspection, adjustment, scheduled maintenance, and repair/removal are included.
Referring to Section 2 will aid in understanding the operation and function of the various compo-
nents and systems of the work platform, and help in diagnosing and repair of the machine.
T
ERMINOLOGY
T
ERMINAL
B
LOCKS
Located in upper and lower control boxes. Designated by TB##.(##) designates the number of the
block which is written on the terminal block. “R” right or “L” may follow the number.
W
IRE
C
OLOR
Indicated by color/color. First color refers to insulation color and second color indicates stripe. If sec-
ond color is not given there is no stripe.
F
ORWARD
Front of machine indicated by yellow arrows on chassis.
A
FT
Rear of machine indicated by orange arrows on machine.
G
ENERAL
P
ROCEDURES
C
ONTACT
B
LOCKS
Removed by inserting a flat screwdriver into the slot at either end of block and prying outward.
Installed by pressing into an empty slot.
S
WITCH
M
OUNT
B
ASE
Assembled to back of switch actuator. Removed by rotating the small black lever counterclockwise
and lifting off base.
T
ERMINAL
B
LOCKS
Remove wires by inserting a small flat bladed screwdriver into square beside wire. Install wires by
stripping 13 mm (½”) of insulation, inserting screwdriver in square and inserting wire. Be sure no
strands are bend backwards. Replace wires with same rating and type.
3.2 D
ATE
C
ODE
I
DENTIFICATION ON
H
OSES
G
ATES
uses a five digit code: Year,Month,Day.
i.e.: 6 11 29 - means 1996
, month 11 (November), day 29.
P
ARKER
uses a ten digit code: Plant, Year, Month, Day.
i.e.: XXXX 6 11 29 - means Plant XXXX, 1996
, month 11 (November), day 29.
D
AYCO
stamps month, day and year on each hose.
WARNING
!
!
Be sure to read, understand and follow all information in the Operation
Section of this manual before attempting to operate or perform service on
any Work Platform.
