Uson 628 - Power Supply Specifications; Connections

Installation/Wiring 3-5
3.2.3 Power Supply Specifications
Input
• Voltage: 100 to 240V AC
• Current: 3.2A Max
• Frequency: 47 to 63 Hz.
Output
• Voltage: 24V DC.
• Current 5.4A max
• Power 70 W
General
• Weight: 0.4 Kg / 0.8 lb net
• Dimensions (D) x (W) x (H): 190 x 85 x 50 mm /7.5 x 3.4 x 2.0 in
3.2.4 Connections
The mains inlet socket is an IEC320-C14.
The DC outlet is a 5 way circular connector for connecting directly to the tester.
The pin connections are:
Pin Connection
1,2,3 0V DC
4,5 +24V DC
Shield Ground
