Program Mode 5-3
5.3.1 Program Menu (submenus)
The Program menu allows the user to set the standard parameters required to
perform a leak test. These parameters cannot be modified when the password
option is enabled. The menu parameters are:
Program Menu Parameters
Parameter Description
Program
The options are:
Load:
Loads an alternative program.
Copy to
: Copies the loaded program to another program.
Reset Program:
Sets the parameters to default values.
Name
This parameter allows the user to set a name for the program
consisting of up to 15 characters. The name defaults to Program X
where X is the program number.
+ Reject Level
This parameter sets the level of leak that the test component is to be
tested against.The programming limits and the default value are
dependent upon pressure units, differential measuring range and
comp/cal options.
- Reject Level
This parameter sets the level of leak that the reference component is
to be tested against.The programming limits and the default value are
dependent upon pressure units, differential measuring range and
comp/cal options.
Pass Result
Sets the pass criteria in-conjunction with the reject levels. The
options are:
Above Reject Max
,
Below Reject Min
and
InBand
(default).
Test Pressure
This parameter defines the test pressure for the Fill 1 step. The Test
Pressure should be set to a value that complies with the test
specification of the test component. The programming limits and the
default value are dependent upon pressure units selected and the
pressure range of the unit.
To set the manual regulator output:
1. Turn the pressure regulator knob fully
counter clockwise
.
2. Use the
left/right arrow keys
to select
regulator output.
3. Select
On function key
to display
regulator output setting
.
4. Turn the pressure regulator knob
clockwise
until the required test
pressure is achieved.
5. If required select, the
Update function
key to set the Test
Pressure parameter to the displayed regulated pressure.
6. Select the
Off function
key to cancel regulator function.
