Getting Started 4-11
4.4 Password Overview
The 628 supports a password scheme to control access to the menu options and
parameters when enabled. Table 4–2 lists the access levels available and the
display background color indicates the level selected. Table 4–3 shows the
password setup menu parameters.
Table 4–2: Password schemes.
Table 4–3: Password Setup Menu Parameters
Level Description
Background
Color
Disabled
This level is selected when the password option is
disabled. All non-protected and User protected menu
items are accessible.
Blue
None
This level is selected when the password option is
enabled and no login has been performed.
Only non-protected menu items can be performed or
modified.
Blue
User
This level is selected when the password option is
enabled and the operator logs in using the user
defined password.
All non-protected and User protected menu items are
accessible.
Grey
Parameter Description
Control
The options are No (default) to disable and Yes to enable
the password option.
Entry
To set a unique password for the tester, minimum 1
character.
Timeout
This parameter defines the elapsed time allowed with no
user activity before being logged out. The range is 0 to 60
minutes, default setting is 10 minutes.
