How To 7-7
6. When the test cycle has successfully finished, the Green and Red LEDs
indicate a Pass or Reject respectively. If a reject condition displays (Red LED),
press the Reset button before starting the next test.
7.2.1 Test Results
Test results are displayed or indicated on the front panel display under the column
“Result” and the front panel lamps. Possible test results are as follows:
The Setup menu parameter Reset Mode parameter controls the operation of the
Tester on reject condition.
Result Description
Gross
Indicates that a leak has been detected that is larger than the
instrument can measure. A Gross leak is displayed as the
maximum leak rate value.
Reject
Indicates that a leak has been detected that is larger than the
reject limit set by the user.
Pass
Indicates that the component under test has passed the test
cycle.
The measure step and final result leak values for pressure and vacuum tests are
displayed as positive values.
