5-6 Uson 628 Operator’s Manual
5.3.2 Comp/Cal Menu
The Comp/Cal menu allows the user to set the standard parameters required to
perform a leak test. These parameters cannot be modified when the password
option is enabled. The menu parameters are:
5.3.3 Linking Menu
The Linking menu allows the user to link test results based on test results and
settings. The parameters are:
Comp/Cal Menu Parameters
Parameter Description
Comp Control
Enables/Disables comp correction being applied to the test result
value.
Comp Value
The pressure drop reading set by the Comp Test for a leak tight
master part or can be manually entered by the user. The Format and
range is dependent upon the differential sensor range and unit
selections.
Cal Control
Enables/Disables the Cal conversion to leak rate being applied to the
test result value.
Cal Value
The pressure drop reading set by the Cal Test for the Leak master
and master part or can be manually set entered by the user. The
Format and range is dependent upon the differential sensor range
and unit selections.
Flow units Specifies the units for the leak rate value.
Leak format Specifies the format for the leak rate value.
Leak Value
Specifies the value used to perform the leak rate calibration for the
Cal test.
Linking Menu Parameters
Parameter Description
Jump Method
Specifies the type of jump to be performed: 
Disabled : No jump performed.
Immediately: Starts next program.
Wait for start: Starts next program after receiving start input signal.
Pause delay: Starts next program after a specified delay.
Jump On
Specifies when a jump is performed based on the test result: Pass,
Fail, Pass or Fail.
Jump to Program Specifies the next program to be performed.
Pause Time
Specifies the delay time required before starting the next test. The
programming range is 000 to 1000.0 s.
Vent Enabled
Specifies if a vent step is performed between linked programs. The
default is enabled to perform a vent step.
