8-4 Uson 628 Operator’s Manual
Cal Test
1. Select Cycle Type.
2. Select Cal and press Start button to enter value.
3. Select Run mode to exit menu.
4. Connect a known good component to the test port.
5. Connect the leak master to the calibration port, or insert the flow orifice into
the test line using a"tee", and ensure that the orifice is blanked off.
6. Press Start button to perform the Cal test cycle.
7. Select Cycle Type.
8. Select Normal and press Start button to enter value.
9. Select Save option to save new comp/cal values.
10. Select Run mode.
11. Perform normal cycles with and without leak master to verify calibration.
Any previous calibration data is cleared when the Start button is pressed. A pass
output indicates the test was successfully completed and Cal test can be
performed. An Abort or Reject result indicates an invalid test which must be
investigated and resolved before continuing.
