3-2 Uson 628 Operator’s Manual
3.2 Wiring/Connections
3.2.1 Rear Panel
Figure 3–1 shows the Uson 628 back panel component layout, Table 3–1 describes
the electrical components’ functions, Table 3–2 describes the pneumatic
components’ functions.
Figure 3–1: .Uson 628 Rear Panel Overview
WARNING: Adhere to all warnings outlined in Section 1, Safety.
WARNING:
1) Uson 628 operates on 24VDC from a power supply which must be
connected to an earthed (grounded) power supply of 100-240VAC 50/60Hz.
2) The covers on the equipment should be removed/replaced only by
personnel trained to avoid the risk of electric shock.
3) Do not plug the Uson 628’s into an electrical power supply until all
installation, wiring, servicing/adjusting, wiring, etc. procedures have been
completed; and all enclosures are in place.
WARNING:
1) Always use the correctly rated fuse. Do not substitute the fuse type or
rating.
2)Do not make or break external connectors or connections while the Uson
628 is switched on.
WARNING: When using a pneumatic couple device with the Uson 628, take
care to ensure that both the couple and the component are adequately
restrained.
