5-12 Uson 628 Operator’s Manual
5.3.10 Regulator Menu
This menu displays the Regulator menu parameters. The menus are:
* Set by manufacturing and cannot be modified.
5.3.11 Hardware Menu
General functions to check hardware operation and should only be used by Uson
personnel: The menus are:
* For Uson Personnel Only.
Regulator Menu Parameters
Parameter Description
Type*
Manual or electronic.
Range*
Pressure range.
Zero
DAC counts for calibration zero reading defaults to 0.
Span
DAC counts for calibration target pressure, defaults to value based
on range selection.
Target
Calibration Target value, defaults to gauge sensor range.
Calibration Date
Last calibration date and time
Hardware Menu Parameters
Parameter Description
ADC*
Displays adc readings.
Digital I/O*
Displays input states and allows individual outputs to turned on and
off.
PWM Control*
Allows regulator control output to be set.
Valve Control*
Allows individual pneumatic valve outputs to turned on and off.
Serial Test*
Reads and writes data to the serial port.
RTC*
Displays current RTC settings.
Cycle Counter*
Displays the total number of test cycles started.
Linux Information
Displays current kernel version.
Software Version
Displays current installed software version and update option.
