2DA/2DB
1-5-16
Problem Causes/check procedures Corrective measures
(29)
A paper jam in the
finisher*
1
is indi-
cated during copy-
ing (Intake jam).
Jam code 81
(30)
A paper jam in the
finisher*
1
is indi-
cated during copy-
ing (jam during pa-
per conveying for
batch ejection 1).
Jam code 83
(31)
A paper jam in the
finisher*
1
is indi-
cated during copy-
ing (jam during pa-
per conveying for
batch ejection 2).
Jam code 84
Defective paper conveying
switch*
1
.
Check if the feedshift roller
or feedshift pulley is de-
formed.
Defective paper conveying
switch*
1
.
Check if the feedshift roller
or press roller is deformed.
Defective paper conveying
switch*
1
.
Check if the eject roller or
eject pulley is deformed.
With 5 V DC present at CN4-9 on the finisher main PCB, check
if CN4-10 on the finisher main PCB remains high or low when
the paper conveying switch is turned on and off. If it does, re-
place the paper conveying switch.
Check visually and replace the pulley or roller if deformed.
With 5 V DC present at CN4-9 on the finisher main PCB, check
if CN4-10 on the finisher main PCB remains high or low when
the paper conveying switch is turned on and off. If it does, re-
place the paper conveying switch.
Check visually and replace the pulley or roller if deformed.
With 5 V DC present at CN4-9 on the finisher main PCB, check
if CN4-10 on the finisher main PCB remains high or low when
the paper conveying switch is turned on and off. If it does, re-
place the paper conveying switch.
Check visually and replace the pulley or roller if deformed.
*1: Optional. *2: Optional for 16 ppm model. Standard for 20 ppm model.
