Utax cd 1120 User Manual

2DA/2DB-1
2-3-12
Connector Pin No. Signal I/O Description
YC10
Connected
to the
paper
feeder*
1
YC11
Connected
to the
cooling fan
motor 2
YC12
Connected
to the
cooling fan
motor 3
YC13
Connected
to the key
counter*
2
YC14
Connected
to the exit
motor
YC15
Connect to
the exit
switch and
feedshift
switch
YC16
Connected
to the
scanner
motor
YC17
Connected
to the
inverter
PCB
1LOPSRDY I Paper feeder READY signal
2LOPSEL2 O Paper feeder SEL2 signal
3LOPSEL1 O Paper feeder SEL1 signal
4LOPSEL0 O Paper feeder SEL0 signal
5 LOPSCLK O Paper feeder clock signal
6 LOPSDI I Paper feeder serial communication reception
7 LOPSDO O Paper feeder serial communication transmission
8SGND - Ground
9 +5V2 O 5 V DC power supply for the paper feeder
10 SGND - Ground
11 +5V2 O 5 V DC power supply for the paper feeder
1 +24V4 O 24 V DC power supply for CFM2
2FAN2DRN O CFM2 on/off
1 +24V4 O 24 V DC power supply for CFM3
2FAN3DRN O CFM3 on/off
1 +24V1 O 24 V DC power supply for key counter
2 KEYCN O Key counter count signal
3SGND - Ground
4 KEYENBN I Key counter set signal
1 COMDA O EM control signal (A)
2 COMDNB O EM control signal (_B)
3 COMDNA O EM control signal (_A)
4 COMDB O EM control signal (B)
1PGND - Ground
2 EXTSMN I ESW on/off
3 SEPSWN I FSSW on/off
4 +5V2 O 5 V DC power supply for ESW/FSSW
1 ISMDA O SM control signal (A)
2 ISMDNB O SM control signal (_B)
3 ISMDNA O SM control signal (_A)
4 ISMDB O SM control signal (B)
1LAMPN O EL on/off
2PGND - Ground
3 +24V1 O 24 V DC power supply for inverter PCB
4 +24V1 O 24 V DC power supply for inverter PCB
5PGND - Ground
6LAMPN O EL on/off
*1: Optional for 16 ppm model. Standard for 20 ppm model. *2: Optional.
