2DA/2DB-1
2-4-10
Maintenance
Section
part/location
Method Maintenance cycle Points and cautions Page
Transfer and Transfer roller Clean - Vaccum or clean with a dry cloth. 1-6-42
separation Separation electrode Check or clean - Clean with the equipped brush.
section
Maintenance
Section
part/location
Method Maintenance cycle Points and cautions Page
Developing Developing unit Check or replace - Replace if the problem occurs. 1-6-41
section
Maintenance
Section
part/location
Method Maintenance cycle Points and cautions Page
Drum section Drum unit Check or replace Every 150,000 counts Replace if the problem occurs. 1-6-38
Maintenance
Section
part/location
Method Maintenance cycle Points and cautions Page
Fixing section Fixing unit Check or replace - Replace if the problem occurs. 1-6-43
Heat roller Clean Every 150,000 counts Clean with alcohol. 1-6-48
Press roller Clean Every 150,000 counts Clean with alcohol. 1-6-45
Heat roller separation Clean or replace Every 150,000 counts Clean with alcohol. Replace if it 1-6-47
claw is being lacking, deformed or
rubbing.
Maintenance
Section
part/location
Method Maintenance cycle Points and cautions Page
Exit section Exit roller Check or clean - Clean with alcohol or a dry cloth.
Exit pulley Check or clean - Clean with alcohol or a dry cloth.
Switchback roller Check or clean - Clean with alcohol or a dry cloth.
Switchback pulley Check or clean - Clean with alcohol or a dry cloth.
Maintenance
Section
part/location
Method Maintenance cycle Points and cautions Page
Covers Covers Clean Every 150,000 counts Clean with alcohol or a dry cloth.
Maintenance
Section
part/location
Method Maintenance cycle Points and cautions Page
Other Image quality Check and adjust Every service
