Installation
February 2011 2-16 P/N 06-237041-001
F i g u r e 2 - 1 2 . A C C o n n e c t i o n s t o P M U B o a r d
(shown without AC Voltage Protection Cover, Standoff and PMU Ground Wire Assembly)
Figure 2-13. AC Voltage Protection Cover (prohibits access to AC Power input terminals)
Ground (Green) Wire Connection
Earth Ground stud
Neutral (White) Wire connection
Line (Black) Wire connection
