You can select the following options:
 Automatic detection. 1D will automatically detect the
bands color scheme according to the defined
percentage of tolerance
 White bands on dark background for images with
white signals and black background
 Black bands on light background for images with black
signals and clear background
Copy to clipboard
This function copies an image, a table or a graph onto the clipboard for insertion into another
program. This option is identical to the Windows
®
[Ctrl C] command.
To proceed, click on the Copy to clipboard icon. The image, the table or the graph is now
ready to be pasted into another application.
Open the application that you want to paste the image into, and select from the available
pasting options ([Ctrl V] command for Windows
®
software).
Image display
Click on the “Image display” to displays the Image Master data as well as the Image Display
set-up.
