Changing direction
Rotation direction of the motor can quickly be changed by applying the FUNCT button.
NOTE! Chang-
ing direction
command is not visible in the menu unless the selected control place is Local.
1. Anywhere in the menu structure, push the Funct button.
2. Push the Arrow up or the Arrow down button to select Change direction and confirm with the OK
button.
3. Then choose the direction you wish to run the motor to. The actual rotation direction is blinking.
Confirm with the OK button.
4. The rotation direction changes immediately and the arrow indication in the status field changes.
Figure 66. Changing direction.
Quick edit
Through the
Quick edit functionality you can quickly access the desired parameter by entering the
parameter’s ID number.
1. Anywhere in the menu structure, push the FUNCT button.
2. Push the Arrow up or the Arrow down buttons to select Quick Edit and confirm with the OK but-
ton.
3. Then enter the ID number of parameter or monitoring value you wish to access. Press OK but-
ton to confirm.
4. Requested Parameter/Monitoring value appears on the display (in editing/monitoring mode.)
