vacon • 194 Non-regenerative front end
Local contacts: http://drives.danfoss.com/danfoss-drives/local-contacts/
Table 90. Fieldbus G2.5
Code Parameter Min Max Unit Default ID Desciption
P2.5.1 Process Data IN1 0 10000 0 876
P2.5.2 Process Data IN2 0 10000 0 877
P2.5.3 Process Data IN3 0 10000 0 878
P2.5.4 Process Data IN4 0 10000 0 879
P2.5.5 Process Data IN5 0 10000 0 880
P2.5.6 Process Data IN6 0 10000 0 881
P2.5.7 Process Data IN7 0 10000 0 882
P2.5.8 Process Data IN8 0 10000 0 883
P2.5.9 ProcessData Out1 0 10000 0 852
P2.5.10 ProcessData Out2 0 10000 0 853
P2.5.11 ProcessData Out3 0 10000 0 854
P2.5.12 ProcessData Out4 0 10000 0 855
P2.5.13 ProcessData Out5 0 10000 0 856
P2.5.14 ProcessData Out6 0 10000 0 857
P2.5.15 ProcessData Out7 0 10000 0 858
P2.5.16 ProcessData Out8 0 10000 0 859
Table 91. Advanced par G2.6
Code Parameter Min Max Unit Default ID Desciption
P2.6.1 OT Alarm Level -30.0 55.0 deg 55.0 1961
If CH62 PT100 sensor is over this
level, alarm will generated
P2.6.2 Fan Type 1 2 2 1962
Cooling fan type selection
1=fan sensor is status sinal, if
signal is low, fault will generate
2=also status signal, fan sensor
signal is inverted, if signal is high,
fault will generate
P2.6.3 Run Start 0 1 0 1963
Start mode selection
0=Rising Edge, run command
need rising edge to restart the
system
1=Auto Start, run command
active, system will auto restart
