Vacon NX User Manual

Appendices vacon • 219
Local contacts: http://drives.danfoss.com/danfoss-drives/local-contacts/
13
CONTROL BOARD
OPTION BOARDOPTION BOARDOPTION BOARDOPTION BOARDOPTION BOARD
CONTROL
PANEL
OPTO
ADAPTER
BOARD
CONTROL UNIT
ASIC
BOARD
DC +
DC -
DRIVER / X13
DRIVER / X14
DRIVER / X15
DRIVER / H4
DRIVER / H5
DRIVER / H6
DRIVER / H9
DRIVER / H7
DRIVER / H8
+ 24 V for
internal fans
C
H62, INVERTER,
C
ONTROL
x) Cable can be removed
if necessary
x)
11413_uk
L1
L2
L3
PE
U / T1
RECTIFIER BOARD
DC+
DC-
MEASUREMENT BOARD 1
MAINS VOLTAGE
SUPERVISION
DRIVER BOARD U
C
H63, F
C
, MODULE 1
11414_uk

Vacon NX Specifications

General

Product Type	AC Drive
Control Method	Scalar Control
Enclosure	IP00, IP21
Communication	Ethernet
Safety	STO (Safe Torque Off)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Ambient Temperature Range	-10°C to +50°C (with derating above +40°C)
Cooling Method	Air-cooled, Liquid-cooled
