Vacon NX User Manual

6
vacon • 82 Electrical cabling and connections
Local contacts: http://drives.danfoss.com/danfoss-drives/local-contacts/
6.1.3.1 AC drives
1
Fuse current (In) 50A for TTF aR fuse.
2
Data in Italic refer to drives with 12-pulse supply
Table 41. Fuse sizes for VACON
®
NX Liquid-Cooled (500 V) AC drives
Chass
is
Type
I
th
[A]
Fuse
size
DIN43620 DIN43653 TTF
Fuse
U
n
[V]
Fuse
I
n
[A]
Qty. of
fuses per
drive
3~/6~
aR fuse
catalog nr.
aR fuse
catalog nr.
aR fuse catalog
nr.
CH3 0016 16 DIN000 NH000UD69V40PV DN00UB69V40L PC30UD69V50TF 690
40/50
1
3
CH3 0022 22 DIN000 NH000UD69V40PV DN00UB69V40L PC30UD69V50TF 690
40/50
1
3
CH3 0031 31 DIN000 NH000UD69V63PV DN00UB69V63L PC30UD69V63TF 690 63 3
CH3 0038 38 DIN000 NH000UD69V100PV DN00UB69V100L PC30UD69V100TF 690 63 3
CH3 0045 45 DIN000 NH000UD69V100PV DN00UB69V100L PC30UD69V100TF 690 100 3
CH3 0061 61 DIN00 NH00UD69V125PV DN00UB69V125L PC30UD69V125TF 690 100 3
CH4 0072 72 DIN00 NH00UD69V200PV DN00UB69V200L PC30UD69V200TF 690 200 3
CH4 0087 87 DIN00 NH00UD69V200PV DN00UB69V200L PC30UD69V200TF 690 200 3
CH4 0105 105 DIN00 NH00UD69V200PV DN00UB69V200L PC30UD69V200TF 690 200 3
CH4 0140 140 DIN1 NH1UD69V315PV PC30UD69V315A PC30UD69V315TF 690 200 3
CH5 0168 168 DIN1 NH1UD69V315PV PC30UD69V315A PC30UD69V315TF 690 400 3
CH5 0205 205 DIN1 NH1UD69V400PV PC30UD69V400A PC30UD69V400TF 690 400 3
CH5 0261 261 DIN2 NH2UD69V500PV PC31UD69V500A PC31UD69V500TF 690 400 3
CH61 0300 300 DIN2 NH2UD69V700PV PC31UD69V700A PC31UD69V700TF 690 700 3
CH61 0385 385 DIN2 NH2UD69V700PV PC31UD69V700A PC31UD69V700TF 690 700 3
CH72 0460 460 DIN3 NH3UD69V1000PV PC33UD69V1000A PC33UD69V1000TF 690 1000 3
CH72
2
0460 460 DIN2 NH2UD69V500PV PC31UD69V500A PC31UD69V500TF 690 700 6
CH72 0520 520 DIN3 NH3UD69V1000PV PC33UD69V1000A PC33UD69V1000TF 690 1000 3
CH72
2
0520 520 DIN2 NH2UD69V500PV PC31UD69V500A PC31UD69V500TF 690 700 6
CH72 0590 590 DIN3 PC73UB69V1100PA PC33UD69V1100A PC33UD69V1100TF 690 1000 3
CH72
2
0590 590 DIN2 NH2UD69V700PV PC31UD69V700A PC31UD69V700TF 690 700 6
CH72 0650 650 DIN3 PC73UB69V1250PA PC33UD69V1250A PC33UD69V1250TF 690 1250 3
CH72
2
0650 650 DIN2 NH2UD69V700PV PC31UD69V700A PC31UD69V700TF 690 700 6
CH72 0730 730 DIN3 PC73UB69V1250PA PC33UD69V1250A PC33UD69V1250TF 690 1250 3
CH72
2
0730 730 DIN2 NH2UD69V700PV PC31UD69V700A PC31UD69V700TF 690 700 6
CH63 0820 820 DIN3 NH3UD69V800PV PC32UD69V800A PC32UD69V800TF 690 800 6
CH63 0920 920 DIN3 NH3UD69V1000PV PC33UD69V1000A PC33UD69V1000TF 690 800 6
CH63 1030 1030 DIN3 NH3UD69V1000PV PC33UD69V1000A PC33UD69V1000TF 690 1000 6
CH63 1150 1150 DIN3 PC73UB69V1100PA PC33UD69V1100A PC33UD69V1100TF 690 1000 6
CH74 1370 1370 DIN3 NH3UD69V1000PV PC33UD69V1000A PC33UD69V1000TF 690 1000 9
CH74
2
1370 1370 DIN3 PC73UB69V1250PA PC33UD69V1250A PC73UB69V13CTF 690 800 6
CH74 1640 1640 DIN3 NH3UD69V1000PV PC33UD69V1000A PC33UD69V1000TF 690 1000 9
CH74
2
1640 1640 DIN3 NH3UD69V800PV PC32UD69V800A PC32UD69V800TF 690 800 12
CH74 2060 2060 DIN3 PC73UB69V1250PA PC33UD69V1250A PC33UD69V1250TF 690 1250 9
CH74
2
2060 2060 DIN3 NH3UD69V1000PV PC33UD69V1000A PC33UD69V1000TF 690 1000 12
CH74 2300 2300 DIN3 PC73UB69V1250PA PC33UD69V1250A PC33UD69V1250TF 690 1250 9
CH74
2
2300 2300 DIN3 PC73UB69V1100PA PC33UD69V1100A PC33UD69V1100TF 690 1000 12

Vacon NX Specifications

General

Product Type	AC Drive
Control Method	Scalar Control
Enclosure	IP00, IP21
Communication	Ethernet
Safety	STO (Safe Torque Off)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Ambient Temperature Range	-10°C to +50°C (with derating above +40°C)
Cooling Method	Air-cooled, Liquid-cooled
