Vacon NX User Manual

Electrical cabling and connections vacon • 83
Local contacts: http://drives.danfoss.com/danfoss-drives/local-contacts/
6
1
Data in Italic refer to drives with 12-pulse supply
Table 42. Fuse sizes for VACON
®
NX Liquid-Cooled (690 V) AC drives
Chassis Type
I
th
[A]
Fuse
size
DIN43620 DIN43653 TTF
Fuse
U
n
[V]
Fuse
I
n
[A]
Qty. of
fuses
per
drive
3~/6~
aR fuse
part nr.
aR fuse
part nr.
aR fuse part nr.
CH61 0170 170 DIN1 NH1UD69V315PV PC30UD69V315A PC30UD69V315TF 690 315 3
CH61 0208 208 DIN1 NH1UD69V400PV PC30UD69V400A PC30UD69V400TF 690 400 3
CH61 0261 261 DIN2 NH2UD69V500PV PC31UD69V500A PC31UD69V500TF 690 500 3
CH72 0325 325 DIN2 NH2UD69V700PV PC31UD69V700A PC31UD69V700TF
690 700 3
CH72
1
0325 325 DIN1 NH1UD69V315PV PC30UD69V315A PC30UD69V315TF 690 315 6
CH72 0385 385 DIN2 NH2UD69V700PV PC31UD69V700A PC31UD69V700TF 690 700 3
CH72
1
0385 385 DIN1 NH1UD69V400PV PC30UD69V400A PC30UD69V400TF 690 400 6
CH72 0416 416 DIN3 NH3UD69V800PV PC32UD69V800A PC32UD69V800TF 690 800 3
CH72
1
0416 416 DIN1 NH1UD69V400PV PC30UD69V400A PC30UD69V400TF 690 400 6
CH72 0460 460 DIN3 NH3UD69V1000PV PC33UD69V1000A PC33UD69V1000TF 690 1000 3
CH72
1
0460 460 DIN1 NH1UD69V400PV PC30UD69V400A PC30UD69V400TF 690 400 6
CH72 0502 502 DIN3 NH3UD69V1000PV PC33UD69V1000A PC33UD69V1000TF 690 1000 3
CH72
1
0502 502 DIN2 NH2UD69V500PV PC31UD69V500A PC31UD69V500TF 690 500 6
CH63 0590 590 DIN3 PC73UB69V1100PA PC33UD69V1100A PC33UD69V1100TF 690 1100 3
CH63 0650 650 DIN3 PC73UB69V1250PA PC33UD69V1250A PC33UD69V1250TF 690 1250 3
CH63 0750 750 DIN3 PC73UB69V1250PA PC33UD69V1250A PC33UD69V1250TF 690 1250 3
CH74 0820 820 DIN2 NH2UD69V500PV
PC31UD69V500A PC31UD69V500TF 690 500 9
CH74
1
0820 820 DIN3 NH3UD69V800PV PC32UD69V800A PC32UD69V800TF 690 800 6
CH74 0920 920 DIN2 NH2UD69V700PV PC31UD69V700A PC31UD69V700TF 690 700 9
CH74
1
0920 920 DIN3 NH3UD69V800PV PC32UD69V800A PC32UD69V800TF 690 800 6
CH74 1030 1030 DIN2 NH2UD69V700PV PC31UD69V700A PC31UD69V700TF 690 700 9
CH74
1
1030 1030 DIN3 NH3UD69V1000PV PC33UD69V1000A PC33UD69V1000TF 690 1000 6
CH74 1180 1180 DIN3 NH3UD69V800PV PC32UD69V800A PC32UD69V800TF 690 800 9
CH74
1
1180 1180 DIN3 PC73UB69V1100PA PC33UD69V1100A PC33UD69V1100TF 690 1100 6
CH74 1300 1300 DIN3 NH3UD69V800PV PC32UD69V800A PC32UD69V800TF 690 800 9
CH74
1
1300 1300 DIN3 PC73UB69V1250PA PC33UD69V1250A PC33UD69V1250TF 690 1250 6
CH74 1500 1500 DIN3 NH3UD69V1000PV PC33UD69V1000A PC33UD69V1000TF 690 1000 9
CH74
1
1500 1500 DIN3 PC73UB69V1250PA PC33UD69V1250A PC33UD69V1250TF 690 1250 6
CH74 1700 1700 DIN3 NH3UD69V1000PV PC33UD69V1000A PC33UD69V1000TF 690 1000 9
CH74
1
1700 1700 DIN3 NH3UD69V800PV PC32UD69V800A PC32UD69V800TF 690 800 12
