CONFIDENTIAL 02.9628.0010
7-Oct-97
4.2.3.9 PCB Assy,
VL4
Voltage Selector (VSB)
24.9628.0026
NO. PART NO. QTY REF DES DESCRIPTION
1 11.9628.0027 1 EA PCB, VL4 VOLTAGE SELECTOR
2 52.6362.0001 2 EA CONN HOUSING, 30 SERIES RED
3 52.8247.0002 2 EA CRIMP CONTACT, S30 TIN (LOOSE)
4 53.2003.0001 4 EA AP: REG1, P5 NUT, 4-40, KEP ZINC PLATED
5 53.6581.0001 2 EA SCREW, 4-40X1 3/8"PPZ
6 53.6596.0001 1 EA AP: REG1, P5 SCREW, 4-40X5/16"PPZ
7 55.2178.0001 1 EA CABLE ANCHOR MOUNT, #8 SCREW
MOUNTING
8 55.2186.0001 1 EA CABLE TIE, SMALL .10X4"
9 55.2203.0001 1 EA SCREW, 4-40X1/4"PPZ
10 55.2204.0001 2 EA WASHER, NYLON #4
11 55.6509.0001 1 EA AP: REG1 WASHER, SHOULDER (HEATSINK)
12 55.6532.0001 1 EA VSB MTG BRACKET BRACKET, UNIVERSAL
13 66.4502.0001 1 EA K1 (BACK SIDE) RELAY, 4PDT, 5A, 12VDC, PC. MNT, SEALED
14 68.4504.0001 1 EA T1 (BACK SIDE) XFMR,5.6 VA, 2 PRI, 2 SEC, AC SLCT BD
15 70.3723.0001 2 EA F3, 4 FUSE, 10AMP, 125V
16 70.3723.0003 2 EA F1, 2 FUSE, 3A, 250V,5X20MM, GLASS
17 73.7027.0018 12 IN WIRE, 18AWG 30KV WHT
50.2708.0001 1 EA XU1 SOCKET, 8PIN DIP
51.5001.0001 1 EA AP: REG1 HEATSINK, TO-220 1" W/PINS
51.5006.0001 1 EA AP: REG1 INSULATOR, TO-220
51.5011.0001 1 EA AP: REG2 MOUNTING PAD, TO-5
52.6230.0001 1 EA P1 PIN HEADER ASSY, MNLOK MALE 3CIR
52.6357.0001 1 EA P4 HEADER, MTA FRCT LOK STRT POST 10PIN
52.6370.0003 1 EA P2 SOCKET HEADER ASSY, MNLOK FMLE 3CIR
52.6370.0004 1 EA P3 SOCKET HEADER ASSY, MNLOK FMLE 4CIR
52.6385.0001 1 EA P6 CONN, EURO 64CONTACTS TYPE "R"
52.8283.0001 1 EA TP1 TERM, SWAGE MT.TURRET
53.6530.0002 1 EA AP: BRACKET RIVET, POP 1/8"OD X .063 -.125 GR.LENGTH
53.6633.0001 2 EA SCREW, 4-1/4"PPZ SHT METAL
55.6691.0001 2 EA AP: BR1, 2 PAD, MNTG. RECTIFIER BRIDGE (VL4)
60.1230.2003 1 EA R3 RES, 1/4W 1% 200K MF
60.1230.5363 1 EA R4 RES, 1/4W 1% 5.36K
60.1421.4701 2 EA R9, 10 RES, 1/4W 5% 4.7K CF
60.1422.1001 2 EA R2, 5 RES, 1/4W 5% 1K CF
60.1423.1004 1 EA R8 RES, 1/4W 5% 1MEG CF
60.1424.1005 1 EA R7 RES, 1/4W 5% 10K CF
60.1426.1003 1 EA R6 RES, 1/4W 5% 100K CF
60.1428.1203 1 EA R1 RES, 1/4W 5% 120 CF
62.2005.0001 2 EA C2, 3 CAP, .01UF, 630V,RAD,POLYEST, .400", 10%
62.2017.0105 2 EA C5, 6 CAP, 1.0UF, 50V,RAD,TANTALM, .125", 10%
62.2027.0475 1 EA C4 CAP, 4.7UF, 35V,RAD,TANTALM, .125", 10%
62.2030.0505 1 EA C7 (BACK SIDE) CAP, 5UF, 200V,AXL,POLYEST, 1.75", 10%
