Vacuum Packaging Machine VC999 K7
Description of the machine
Page 16/121 Art.-No. 592.016 2008-11-26
Legend
1 Cockpit with interactive display
2 Loading area limit mark
3 Conveyor belt joint (plastic wire)
4 Loading area limit mark
5 Conveyor belt
6 Tensioning lever for conveyor belt tension
7 Start button for automatic operation
8 Vacuum pump positions (vacuum pumps)
9 Height adjustable foot
10 Electrical cabinet with control unit
11 Right-hand bag waste suction tube (VC999 K7A)
12 To the bag waste suction unit (VC999 K7A)
13 Vacuum chamber bottom
14 Emergency stop buttons
15 Vacuum chamber lid
16 Terminal box with vacuum sensor
17 Outfeed roller conveyor
18 Lifting mechanism
19 Name plate
20 Cabinet for energy supply (electric / pneumatic)
21 Left-hand bag waste suction tube (VC999 K7A)
22 Electrical connection
23 Compressed air connection
24 Upper sealing bars, cutter blade (VC999 K7A), perforation blade (VC999 K7B), pre-perforation
25 Lower sealing bars
26 Main switch
Cockpit (1)
The cockpit is located directly above the conveyor belt and can be operated from either side of the ma-
chine. It includes all operating elements for operating the Vacuum Packaging Machine.
Programming of packaging cycles is done on the interactive display.
Here, you can also display the individual parameters and edit their values. A keyboard appears for en-
tering data.
Vacuum generation with vacuum chamber
The vacuum generation unit and vacuum chamber form the central sub-assembly of the Vacuum Pack-
aging Machine. One or more vacuum pumps can be provided for vacuum generation to meet customer
requirements.
The vacuum chamber consists of the vacuum chamber lid (15) and the vacuum chamber bottom (13). A
lifting mechanism lowers the vacuum chamber lid onto the vacuum chamber bottom and raises it again
after vacuuming.
