vc999 K7 - Page 76

Vacuum Packaging Machine VC999 K7
Error display and troubleshooting
Page 76/121 Art.-No. 592.016 2008-11-26
No Alarm messages Cause Remedy
39 Error infeed Various causes are possible
Search and eliminate error in
the infeed control
40 Error outfeed Various causes are possible
Search and eliminate error in
the outfeed control
41
Hand safety guard safety
switch jumper
Hand safety guard safety switch
jumper defective OR Hand safety
guard safety switch jumper instal-
led incorrectly
Adjust or replace the hand safe-
ty guard safety switch jumper
42
Hand safety guard monito-
ring defective
Hand safety guard safety switch
defective OR Hand safety guard
safety switch installed incorrectly
Adjust or replace the hand safe-
ty guard safety switch
Error codes for alarm-20
No. Cause Measure during initial
start-up
Measure when the machine is in
operation, heating conductor not
changed
101 I
R
signal missing Fault range Fault range
102 U
R
signal missing Fault range Fault range
103 U
R
and I
R
signal missing Fault range Fault range
104 Temperature jump
Fault range
(loose contact)
Fault range
(loose contact)
105
Frequency fluctuation, imper-
missible power frequency
Check mains Check mains
106 Internal fault Carry out RESET Carry out RESET
107 Internal fault, device defective Replace device Replace device
108 U
R
and/or I
R
signal incorrect Carry out AUTOCAL Fault range
109 Data error Carry out AUTOCAL ---
110
I
R
signal incorrect, calibration
not possible
Fault range
Check configuration
---
111
U
R
signal incorrect, calibration
not possible
Fault range
Check configuration
---
112
U
R
and I
R
signal incorrect, cali-
bration not possible
Fault range
Check configuration
113
Temperature fluctuates, cali-
bration not possible
