Vertiv | NetSure™ 8200 Series -48 VDC Power System Installation Manual (IM582140000) | Rev. A
121
Figure 78:
Bay-Bay Interconnections
Primary Power/Distribution Bay
Primary Power Only Bay Similar
Secondary Power Only Bay
Secondary Power/Distribution Bay Similar
Distribution Only Bay
See Detail A See Detail B See Detail C
