Vertiv | NetSure™ 8200 Series -48 VDC Power System Installation Manual (IM582140000) | Rev. A
22
Figure 3: Floor Mounting Hole Dimensions - Distribution Only Bay (all dimensions in inches)
Floor Hole Drilling Pattern
Distribution Only Bay
Front
3/8-16
Welded Nut (4)
0.812 Dia.
(8 PLACES)
25.875
23.250
27.625
25.375
19.500
26.625
24.000
3.063
1.750
1.875
2.750
4.063
30.000
31.375
19.500
5.937
