Vertiv | SmartCabinet | User Manual 7
Introduction
The major components of the SmartCabinet solution are listed in Table 1-1.
Table 1-1 Major Components
System Type Component Primary function Feature
Rack
supporting
system
-
This component is used
to store the 18U to 28U
rack-mounted hardware
equipment and complies
with the industry-standard,
i.e. EIA-310-D. Examples
of equipment mounted
include servers, voice &
data equipment, Internet
Network Equipment, and
UPS among others
The whole cabinet system is totally enclosed during
the course of operation in order to keep the system
clean and dust-proof; meantime, the noise is reduced
and signicant amount of energy is saved.
Power Supply
& Distribution
system
PMU (Power
Management
Unit)
Power distribution & Surge
suppression
This module provides AC & DC power supplies for
the SmartCabinet solution; it also ensures Level
C lightning protection for the cabinet; Centralized
management over power supply & distribution of
the whole system; One-route input & multi-route
output control function; ease of use and convenient
operation
UPS & Battery Power Supply
The UPS & battery provide high quality electric
energy input for the various IT Devices while
maintaining high availability.
PDU (16-ports)
Power distribution
(Applicable to both the
Integrated as well as the
Standard model)
Congured along with the Switch Model PDU, it can
turn output ports ON/OFF intelligently; it also detects
input/output electric quantity parameters; 2nd port
- supports Emergency Fan Power (used by the
system).
PDU (24-ports)
Power distribution
(Applicable to only the
Standard model)
LED Lamp System Auxiliary lightning
Makes the system Safe and enables considerable
energy-savings.
Air
Conditioning
system
Air conditioner
Cooling the electronic
devices inside the cabinet
eectively
Small-sized precision environmental control
system using the frequency conversion technology;
specically designed for cooling of electronic devices
while maintaining high energy-eiciency ratio; auto
adjustment capabilities keeping the environment in
the cabinet stable for safe and reliable operation of
IT devices.
Emergency
Ventilation
system
Prevents high temperature
partially internally in the
cabinet
If the temperature inside the cabinet increases over
the specic level (overtly high temperature) or the air
conditioner shuts down or fails, an emergency device
will start up automatically to prevent the devices
from operating in high temperature. This emergency
kit is powered o during normal operation to
ensure air tight environment in the system and high
eiciency cooling of the air conditioner.
