Introduction
1.3. Ambient Requirements
The Operating conditions and Storage conditions are listed in the following Table 1-2.
Table 1-2 Operating Environment
Item Requirement
Model
600/800mm wide Standard Unit 600mm Wide integrated condenser unit
MSC-XXS65XBXXXXX,
MSC-XXS85XBXXXXX
MSC-XXI652AXXXXX
Installation
Position
The installation eld has to be levelled; Space
height should not be less than 2400mm for
installation of the Smart Cabinet unit. The
condenser unit cannot be placed on top of the
SmartCabinet in this case. Equivalent horizontal
distance between the indoor unit & outdoor unit
of the AC: 20m; Vertical distance ∆H: -5m ≤ ∆H ≤
10m
Ensure that the installation eld is levelled and
space height is not less than 2300mm.
Installation
Field
In the computer room or oice, the distance from
the front/rear door to the wall or other obstacles
is larger than 1.0m
The clearance among the room, oice areas, front/
rear doors, the wall or obstacles should be greater
than 1.0m. The clearance between the side door
and wall or obstacles should be greater than 45cm.
Environmental
requirements
Indoor*: 0° ~ 40°C
Outdoor unit of the air conditioner;
standard model: (-15°C ~ +45°C)
0° ~ 40°C
Ambient
Humidity¹
30%RH ~ 95%RH
Altitude² Derating is required when the altitude is above 1000m
Operation
Voltage range
P+N+PE, 220V AC/230V AC/240V AC
• During operation in high temperature and high humidity environments, condensate water may appear on the
external surface of the front glass door and display panel; however, this is a normal phenomenon and doesn’t
aect the operations or usage.
• Refer Liebert® ITA2 5kVA ~ 20kVA UPS User Manual and Liebert® ITA 3kVA UPS User Manual for derating
concerns of the UPS.
Table 1-3 Storage Conditions
Item Requirement
Storage Environment Indoor, clean without dust
Ambient Humidity
5%RH ~ 95%RH
Ambient Temperature
-15°C ~ +50°C
