Vertiv | SmartCabinet | User Manual 17
System Installation
2.1.1. Transportation & Movement
Railroad is the preferred transport option. If transport by rail is unavailable, transport by road is recommended.
When selecting road transport, roads without too many bumps are strongly recommended.
The appearance of the entire package, inclusive of components is shown in Figure 2-5.
Figure 2-5 Package inclusive of components
The dimensions of the package are depicted in the following Table 2-5.
Table 2-5
Component Packaging
Range of Dimensions (Unit: mm)
Range of Weight
(Unit: Kg)
H W D
Cabinet
component
with
package
600mm-wide
Standard Cabinet
Paper Box 2240 766 1416 <373 kg
Wooden Box 2270 766 1416 <478 kg
800mm-wide
Standard Cabinet
Paper Box 2240 966 1416 <403 kg
Wooden Box 2272 966 1416 <515 kg
600mm-wide
Cabinet with
Integrated
Condenser
Paper Box 2260 766 1416 <374 kg
Wooden Box 2372 766 1416 <485 kg
To Next Page
