Vertiv | SmartCabinet | User Manual 16
System Installation
Sr. No. Product Name Quantity Note
8 Dummy Plate 1 (set)
9 Access control card
(optional)
2
10 Copper Pipe 2
Accessory Box 2
11 Sealing Glue 1
12 Copper pipe
binding strip
1
For the 600mm unit with the Integrated Condenser
Sr. No. Product Name Quantity Note
1 Cable Tie 30
Accessory Box 1
2 Cable Tie Fixture 10
3 OT Terminal 4
4
Floating Nuts, M6
Panel screw
30 (set)
5 Floating Nut Hook 1
6
MSC Intelligent
Monitoring Card
1 (set)
7 Hairbrush 1
8 Dummy Plate 1 (set)
9 Access control card 2
Self Prepared Materials
The cables routed from the room to the SmartCabinet and the circuit breakers must be prepared at the
customer site or are to be obtained by the customer; the specications for the same are given in the
Table 2-4.
Table 2-4
Parts Specications
External Circuit Breaker 1P 50A-level isolation switch
Input power supply cables Cable CSA: 6mm² (ambient temperature: 25°C)
System Grounding cables
Yellow / Green cable CSA: 6mm² (ambient
temperature: 25°C
Network management cables CAT5E
