VF HF-50 - Detectors Response; Tab. 11 the Meanings of Values in the Table with the Status of Detectors

Instructions for use
VF1807090083 EN revision 53
First row of
the heading
Second row
of the
heading
Value meaning
Imp
A/B
Current counts sent in the respective measuring channel in one sampling period.
Sampling period is set to 1 s for hand and foot detectors and to 200 ms for the
frisker.
status det.
msg
Information regarding communication with the detector:
PROCESS – the instrument reads information sent from the detector
TIMEOUT – the instrument does not have any connection with the detector
status
1
Detector status is composed of three bit masks
2
in a hexadecimal form:
Global status – the meanings of bits are given in Annex F,
Status of power supply – the meanings of bits are given in Annex F,
Status of HV power supply unit – the meanings of bits are given in Annex F.
err.param
A/B
When the detector is not correctly set, the following errors
3
of the detector may
occur:
33 – No nuclide is enabled in detector configuration
34 – Channel index is not 0 for A or 1 for B
35 – Eff must not be 0
Tab. 11 The meanings of values in the table with the status of detectors
6.5.8 Detectors response
You can use the “Detectors response” option to verify by means of the appropriate CRM the accuracy and
correctness of measurement for individual detectors and determine the response factor, see K1010-01-BT01.
 Hold the CRM closely to the detector.
 Set the measuring time (field on the right).
 Press the “Start” button to run the measurement procedure.
 After the measurement, the measured values are displayed on the screen for each detector
(indicated by a pictogram) and measuring channel (A, B). The values are given as total counts per
set measuring time.
 You are returned to the service menu by pressing the red arrow in the upper part of the screen.
The maximum number of pulses is 65535. Will be followed counting from zero.
1
Information is used for service purposes. Contact service organisation if error indicated.
2
The bit mask consists of eight binary digits - bits - which can have values (0 or 1). Each bit means a prescribed condition. Bits are
read from the right to the left (from the lowest to the highest one) and they are marked from 0 to 7 - for example 00000011, where bit
0 has the value of 1, bit 1 has the value of 1, bits 2 to 7 have the value of 0. The whole eight-bit recording is transferred from the
binary system to the hexadecimal system, namely 00000011 is written as 0x03. 0x is a prefix specifying a recording in the hexadecimal
system.
3
Errors of the detector can be removed by changing the setting of detectors via service SW. Settings shall be performed by the
manufacturer, service organization trained by the manufacturer, or the user's staff trained by the manufacturer.
