VHF Z4 - Establishing the electric connection; Removing the transport lock

Establishing the electric con-
nection
NOTICE
Damaging of the machine through heavy
voltage fluctuations
Heavy voltage fluctuations can disrupt the control unit
and can cause system failures.
Plug the machine’s power cable in a dedicated
current circuit or ensure that no devices are con-
nected that can cause heavy voltage fluctuation
when switched on.
If heavy voltage fluctuations cannot be avoided,
install a suitable device which protects the
machine from heavy voltage fluctuations.
NOTICE
Short-circuit hazard when the machine is
too cold
If the machine is transported from a cold environment
into a warmer environment, a short circuit may occur
caused by condensate.
Before
switching on the machine after trans-
portation, ensure the following:
n
The ambient air has the allowed temperature.
n
The machine has the same temperature as the
ambient air. This will take
at least
48hours.
n
The machine is completely dry.
The machine requires a continuous power supply for
proper operation.
1.
Plug the provided power cable into the power
connection at the connection panel of the
machine.
2.
If power failures occur regularly at the installation
location or if there are frequent voltage fluc-
tuations, install an online Uninterruptible Power
Supply (UPS).
If a power failure occurs during job execu-
tion, the tool may break and the blank
may be destroyed.
3.
Insert the plug of the cable into a socket that is
protected by a Residual Current Device/ Ground
Fault Circuit Interrupter.
Removing the transport lock
Before operating the machine for the first time, you
must remove the transport lock. The transport lock
prevents the spindle from getting damaged during
transport.
1.
Ensure the following:
n
The machine is connected to the electrical
source.
2.
Switch on the machine at the main power switch.
3.
Press the start button.
The machine references.
4.
Open the working chamber door by
selecting the upper arrow of the depic-
ted icon on the touchscreen.
5.
Remove the transport lock as shown in the sup-
plement.
Checking the tool magazines in
the drawer
After you have removed the transport lock, you should
open the multi-purpose drawer and check the tool
magazines.
1.
To unlock the multi-purpose drawer,
select the lower arrow of the depicted
icon in the
Home
section of the touch-
screen.
After a couple of seconds, the drawer will open.
2.
Pull the drawer open.
3.
Remove the transport protection cover from the
tool magazines.
4.
Verify that there are 5 tool magazines with dif-
ferent color codes in the drawer.
5.
To close the multi-purpose drawer, push it until it
locks back in place.
You will hear a clicking sound.
More information on tool magazines and
managing tools:
Ž
Managing tools
– on
page41
