16: Configuring VLAN
_______________________________________________________________________________________________________
_____________________________________________________________________________________________________
© Virtual Access 2017
GW1000 Series User Manual
Issue: 1.9 Page 128 of 350
Web: IPv4 gateway
UCI: network.VLAN1.gateway
Opt: gateway
IPv4 default gateway to assign to this interface (optional).
Web: Use custom DNS servers
UCI: network.VLAN1.dns
Opt: dns
List of DNS server IP addresses (optional).
Table 41: Information table for VLAN general settings
16.3.3 Firewall settings: VLAN
Use this section to select the firewall zone you want to assign to the VLAN interface.
Select unspecified to remove the interface from the associated zone or fill out the
create field to define a new zone and attach the interface to it.
Figure 70: Firewall settings page
When you have added all the VLAN interfaces you require, click Save & Apply.
16.4 Viewing VLAN interface settings
To view the new VLAN interface settings, in the top menu, select Network ->
Interfaces. The Interfaces Overview page appears.
The example below shows two VLAN interfaces configured.
