30: Dynamic Multipoint Virtual Private Network (DMVPN)
_______________________________________________________________________________________________________
_____________________________________________________________________________________________________
© Virtual Access 2017
GW1000 Series User Manual
Issue: 1.9 Page 284 of 350
30.4 Configuration packages used
Package
Sections
network
For configuring the GRE tunnels.
strongswan
For enabling and configuring the IPSec connection
template
dmvpn
30.5 Configuring DMVPN using the web interface
The DMVPN section contains fields required to configure the parameters relative to the
DMVPN Hub. These are used for DMVPN tunnels, such as GRE tunnels, GRE tunnel
remote IP, DMVPN Hub IP and password.
30.5.1 DMVPN general settings
In the top menu, select Network -> DMVPN. The DMVPN page appears. There are two
sections: General and DMVPN Hub Settings.
Figure 143: The DMVPN general section
Web Field/UCI/Package Option
Description
Web: Enable DMVPN
UCI: dmvpn.common.enabled
Opt: enable
Enables DMVPN.
0
Disabled.
1
Enabled.
Web: IPSec template connection
UCI:
dmvpn.common.ipsec_template_name
Opt: ipsec_template_name
Selects the IPSec connection, defined in strongSwan, to be used
as a template.
Table 98: Information table for DMVPN general settings
